AIM-100® double ceiling

click to enlarge

Providing both amazing value and unparalleled aesthetics, Burton’s AIM-100“® delivers very smooth focus and superior maneuverability. A longer arm system ensures that either light can be positioned in the widest range of positions possible, making it ideal for surgical applications.


  • High-intensity of 63,000 lux (5852 fc) at 1 meter (per lighthead on double ceiling model)
  • 3500 K color temperature offers natural and true coloring
  • High CRI (Color Rendering Index) of 97
  • Uses three quartz halogen bulbs (per lighthead on double ceiling model) – each rated with a 2000-hour bulb life; bulbs wired in parallel for continuous operation
  • Compact 20″ (51 cm) diameter lighthead
  • Extremely smooth focus mechanism with center sterilizable handle
  • 360° limitless arm-and-mounting-system-rotation around vertical axes (on single ceiling models)
  • Cool operation for long hours of use
  • 120V standard; 100 and 230 / 240V models available
  • 5-year limited warranty
  • Assembled in USA


  • UL/IEC 60601-1, IEC 60601-1-2, EN/IEC 60601-2-41 and CAN/CSA C22.2 NO. 601.1 M90 certified
  • CE marked

Ordering Information

  120V   230/240V   230V SP*   100V   Description
  A100FL   A103FL   A102FL25   A101FL   Floorstand
  A100SC   A103SC   A102SC25   A101SC   Single ceiling mount
  A100DC   A103DC   A102DC25   A101DC   Double ceiling mount
  A100W   A103W   A102W25   A101W   Wall mount


Model Description
  1017111PK   Set of 3 AIM-100 replacement bulbs
  1017040   Sterilizable / Autoclavable handle
  0008100PK   Disposable handle covers, 25/box
  1017084   42″ drop tube

*SP Model refers to Spanish Language Manuals.
