Nova Exam^® LED

LED

Nova Exam LED meets the demands of today’s clinical examination applications. The LED Chip-on-Board light source produces light that enhances physician/patient comfort while delivering a high illuminance level and a highly-uniform beam pattern. A sleek head design, combined with a patented K-arm, allows quick and reliable positioning while being easy to clean and maintain. Economical benefits include less maintenance and longer light-source life.

Designed for Patient Comfort and Ease of Use

• The LED source provides a virtually heat-free light so the patient remains comfortable
• Dual handles are easily accessible to position the light head
• The patented K-arm moves smoothly with no drifting

Enhanced Performance

• Nova Exam^® LED delivers a uniform beam pattern that aids the examination process
• Dual intensity switching allows a choice between two illumination levels. The low level delivers a 19% increase in light level with only 8W of LED power compared to a 20W halogen option. The high level delivers an 11% increase in light level with only 16W of LED power compared to a 35W halogen option.
• Maximum arm reach of 45″ (114.30 cm)
• Delivers consistent light output during power supply fluctuations

Lower Cost of Ownership

• The sleek light head aids routine cleaning
• The LED source offers 10x the operational life of traditional halogen solutions
• 58% energy savings over comparable halogen options (at low light level setting) and 18% savings when providing double the illumination

Technical Specifications

• Illuminance, Low Level: 45,000 lux (2323 fc) at 18″ (46 cm)
• Illuminance, High Level: 90,000 lux (4645 fc) at 18″ (46 cm)
• 4100 K color temperature
• CRI (Color Rendering Index) of >95
• Two LED light modules with a 50,000-hour life each
• Low Level: 7 Watts
• High Level: 14 Watts
• Maximum arm reach of 45″ (114.3 cm)
• Available in a variety of mounting options – Mobile Floor Stand, Table, Wall or Ceiling – to fit any application. (Rail Mount sold separately)
• 5-year limited warranty

Certifications/Approvals

• IEC 60601-2-41 (2013) ANSI/AAMI ES60601-1:2005 and A!:2009/(R)2012, CSA CAN/CSA-C22.2 NO. 60601-1:14

Ordering Information
